Model NO. |
GJFJTC8Y |
|
Fiber type |
9/125, 50/125,62.6/125 |
|
Sheath color |
Black |
|
Sheath material |
PE |
|
Cable dimension (mm) |
4.2-8.5, Tolerance±0.1 |
|
Cable weight (Kg/km) |
19-40 |
|
Min. bending radius (mm) |
30 (Static) 15(Dynamic) |
|
Attenuation (dB/km) |
≦ 0.4 at 1310nm ≦ 0.3 at 1550nm |
 1 Small outer diameter, light weight |
 1 Standard core can be directly apply to connectors,to use for device connecting. |
 1 Aramid stranded wire has extremely high tensile strength, convenient for self-supporting; 2 Air-mounting. |
