Model NO.
|
GJFH |
|
Fiber type |
9/125 |
|
Sheath color |
Green or Customized |
|
Sheath material |
LSZH or PVC |
|
Cable dimension (mm) |
3.0,3.5, Tolerance±0.1 |
|
Cable weight (Kg/km) |
7.5/8.0 |
|
Min. bending radius (mm) |
100 (Static) 50(Dynamic) |
|
Attenuation (dB/km) |
≦ 0.4 at 1310nm ≦ 0.3 at 1550nm |
 1 Good uniformity of the outer diameter of tight buffer fiber. 2 Easy to strip. |
 1 Can be made for patch cords, MTP/MPO, pigtails. |
 1 Package and shipment 2 Customized outer sheath |
