Model NO. |
GJFJU |
|
Fiber type |
9/125(G657A2/G657B3) |
|
Sheath color |
Black or Customized |
|
Sheath material |
TPU |
|
Cable dimension (mm) |
3.0, 3.5… Tolerance±0.1 |
|
Cable weight (Kg/km) |
2.5~35 |
|
Min. bending radius (mm) |
20 (Static) 10(Dynamic) |
|
Attenuation (dB/km) |
≦ 0.4 at 1310nm ≦ 0.3 at 1550nm |
 1 Excellent abrasion resistance and cold temperature workability |
 1 Soft, flexible, easy to lay and splice, and with big capacity transmission. 2 Good bending performance. |
 1 Suitable for making SC/LC patchcord or pigtail. |
