Model NO. |
GDPFH-4B6+2×4MM2 |
|
Fiber type |
G657 |
|
Sheath color |
Black |
|
Sheath material |
LSZH |
|
Cable dimension (mm) |
13.0, Tolerance±0.1 |
|
Operation temperature (℃) |
-20~+60 |
|
Min. bending radius (mm) |
20 (Static) 10(Dynamic) |
|
Attenuation (dB/km) |
≦ 0.4 at 1310nm ≦ 0.3 at 1550nm |
 1 Good uniformity of the outer diameter of tight buffer fiber. 2 Easy to strip. |
 1 Highly flexible construction allows for multiple deployments. |
 1 Good bending performance |
